80GHz FMCW high-temperature radar level transmitter with flange mounting and heat sink design. It provides ±2mm high-accuracy, non-contact level measurement for liquids and solids in high-temperature tanks, supporting 4-20mA/HART output. Suitable for steam, high-temp oil, and corrosive media, with IP67 protection for industrial harsh environments.
High Accuracy: ±2mm measurement error for precise inventory control.
High Temperature Resistant: Integrated heat sink for reliable operation in high-temperature tanks.
Non-Contact: No wear, no contamination, no need for regular cleaning or calibration.
Anti-Interference: Works stably with steam, foam, and dust.
Easy Installation: Flange-mounted design, plug-and-play, no complex setup.
Wide Compatibility: Supports multiple communication protocols for seamless integration.
Durable & Safe: IP67 protection, optional explosion-proof certification for industrial safety.
0Details
1.Transmission frequency: 76GHz~81GHz
2.Measurement range: 15m; 35m; 85m；120m
3.Measurement accuracy: ± 2mm or customized
4.Measurement interval: fastest 100ms
5.Beam angle: 3 °/8 °/20 °
6.Use dielectric constant range ≥ 2
7.Power supply range: 18~28VDC, 220VAC
8.Communication method: MODBUS bus; HART
9.Signal output: 4~20mA or RS-485
10.Fault output: 3.6mA, 22mA, hold
11.On site operation/programming: 128 × 64 dot matrix display screen/4 buttons; Configurable upper computer setting software
12.Process temperature/humidity: T0: -40~85 ℃/humidity ≤ 95% RH; T1: -40~200 ℃; T2:-40~400℃； T3:-40~800℃
13.Shell material: aluminum alloy, stainless steel
14.Process connection type: pipe thread/universal flange/anti-corrosion flange/sanitary chuck/quartz isolation flange
15.Process pressure: -0.1-2MPa
16.Product size: ≈ φ 100 * 240mm
17.Cable entrance: M20 * 1.5; 1/2NPT
18.Recommended cable: AWG18 or 0.75mm ²
19.Protection level: IP67/IP66
20.Explosion proof grade: Exia IICT6 Ga; Exdb IICT6 Gb； Extb IIIC T80℃Db
21.Installation method: thread, flange, bracket, chuck or gantry, etc
22.Net weight/gross weight: ≈ 1.50kg~7.50kg
23.Packaging box size: 280 * 280 * 280mm
